The Bosch Motorsport WDD2 direct wiper motor uses a 12-pin Molex connector (31034-5016) for power and bus control. This set (F02U.B01.350-01) provides the matching harness-side mating connector — Molex 31034-516 — for terminating the loom that drives the motor.
It fits both shaft versions of the Bosch Motorsport WDD2 Direct Wiper Motor (Long Shaft 105 mm and Short Shaft 85 mm), which share the same connector.
WDD2 Connector Pinout
Only 5 of the 12 positions are used by the WDD2:
| Pin |
Function |
| 4 |
LIN |
| 6 |
GND |
| 8 |
UBAT (battery supply) |
| 11 |
CAN_H |
| 12 |
CAN_L |
Pins 1, 2, 3, 5, 7, 9 and 10 are unused.
Compatible Motor
