Bosch Motorsport MS 6.2 EVO

The Bosch Motorsport MS 6.2 EVO manages gasoline engines up to 12 cylinders with port fuel injection and is the highest-specification PFI unit in the MS 6 EVO range. Compared to the MS 6.1 EVO, it adds 17 additional analog inputs (38 total) and LTE Ethernet telemetry support — the two features that most often differentiate endurance racing installations from sprint or single-make applications. The wider analog input count supports more complete sensor coverage: additional pressure sensors, exhaust temperature channels, and chassis inputs can all be wired directly without a separate signal-conditioning module.

LTE telemetry allows live channel streaming to the pit wall for real-time monitoring, strategy, and driver coaching. Dual electronic throttle control, variable valve timing, active turbo management, traction control, and integrated gearshift management are all supported in the base software. The 4 GB standard logging memory can be expanded with the FULL_LOG_1 upgrade to 1,500 channels at 1,000 Hz, and a second 4 GB partition activatable via the FULL_LOG_2 key provides a dedicated long-term recording partition.

All MS 6 EVO software upgrades — including gear control packages, drag racing packages, and the Customer Code Area for MATLAB/Simulink algorithm development — are compatible with the MS 6.2 EVO.

Technical Specifications

What You Can Do With It

• Control port-injected gasoline engines up to 12 cylinders at up to 12,500 rpm
• Monitor 38 analog sensor channels simultaneously — pressures, temperatures, positions, lambdas
• Stream live data to the pit wall via LTE Ethernet telemetry for real-time strategy
• Control two independent electronic throttle bodies for split-plenum or V-engine installations
• Manage variable valve timing, active turbo control, traction control, and launch control
• Run integrated gearshift torque management — cut, blip, and transmission protection in one system
• Log up to 4 GB of data at standard rate; expand to 1,500 channels at 1,000 Hz with FULL_LOG_1
• Develop and deploy custom vehicle algorithms in MATLAB/Simulink via the Customer Code Area

Available Software Upgrades

The following field-upgradeable software packages are available for the MS 6.2 EVO:

• FULL_LOG_1 — activates 1,500 channels at 1,000 Hz (license key)
• USB Data — enables data copy to USB flash drive (license key)
• FULL_LOG_2 — activates a second 4 GB logging partition
• Gear Control Package 1 — MEGA-Line gear control functionality
• Gear Control Package 2 — Bosch Motorsport gear control functionality
• SW Package MS 6 Drag 1 / Drag 2 — drag racing strategy functions
• CCA Hardware Upgrade — enables MATLAB/Simulink customer code deployment
• Innovation License / Innovation Package — advanced function development access

MS 6 EVO Family Comparison

Accessories

• MSA-Box II — USB calibration interface for RaceCon (kept in stock)
• WinDarab V7 — professional data analysis software (license key)
• Software Upgrade FULL_LOG_1 — 1,500 channels at 1,000 Hz (license key)
• Software Upgrade USB Data — USB data copy (license key)
• Lambda Sensor LSU 4.9 — wideband lambda for direct ECU input
• Knock Sensor KS4-R — engine block knock detection
• DBW 82 mm Throttle Body — drive-by-wire throttle body for ETC
• DBW 60 mm Throttle Body — drive-by-wire throttle body for ETC
• Gear Shift Sensor GSS-2 — steering column or gearstick shift sensor

FAQ

Why choose the MS 6.2 EVO over the MS 6.1 EVO?

The MS 6.2 EVO provides 38 analog inputs vs 21 on the MS 6.1, covering complex sensor installations without a secondary acquisition module. It also adds LTE telemetry support for live pit wall data streaming — a common requirement in endurance GT and touring car racing. If neither high channel count nor telemetry is required, the MS 6.1 EVO is a more cost-effective choice.

Does the MS 6.2 EVO support direct injection (GDI)?

No. The MS 6.2 EVO is a port fuel injection ECU only. For GDI or combined LP/HP injection, use the MS 6.3 EVO or MS 6.4 EVO.

What hardware is needed for LTE telemetry?

The MS 6.2 EVO includes software support for LTE Ethernet telemetry. The Bosch Motorsport LTE65 telemetry modem connects to the ECU via Ethernet and provides the wireless link. Contact XTRA Motorsport for current LTE65 availability.

How does the MS 6.2 EVO logging work?

Standard logging is 100 channels at 20 Hz (50 ms) using 4 GB internal memory. The FULL_LOG_1 upgrade activates 1,500 channels at 1,000 Hz. FULL_LOG_2 adds a second 4 GB logging partition — useful for back-to-back session recording without downloading between runs.

Is the MS 6.2 EVO compatible with MS 6.4 EVO software?

Yes. The MS 6.2, 6.3, and 6.4 all run the standard MS 6 EVO software platform in RaceCon. The only MS 6 EVO variant with a separate, incompatible software version is the MS 6.4P EVO.
